Air Intake Pipe for Sinotruk HOWO

- High-strength rubber with nylon cord reinforcement, anti-aging & anti-cracking
- High and low temperature resistance, suitable for long-term engine compartment use
- Good flexibility, strong deformation resistance, no air leakage
- Smooth inner wall reduces intake resistance, improves engine efficiency
- Standard flange & clamp interface, direct installation without modification
- Excellent oil resistance and corrosion resistance

Product Parameters

- Overall Length: 420mm

- Inner Diameter: Φ76mm / Φ80mm

- Outer Diameter: Φ90mm

- Material: EPDM rubber + nylon cord

- Mounting Hole Diameter: Φ10mm

- Net Weight: Approx. 0.8kg

- Working Temperature: -30℃ ~ +150℃

- Working Pressure: 0~0.4MPa

Product Introduction

This air intake pipe is used to connect the air filter housing and turbocharger inlet for Sinotruk HOWO trucks. Made of high-grade reinforced rubber, it withstands high temperature, oil and pressure while maintaining flexibility. The smooth inner wall ensures stable air flow, and good sealing prevents dust from entering. It is a key part for normal engine breathing and long service life.

Applicable Models

- Sinotruk HOWO 7 Series (336HP, 371HP, 380HP, 420HP)

- Sinotruk HOWO A7, T7H, TX, TH7

- Sinotruk HOWO N7, MAX Series

- Engines: WD615, D10, D12, WP10, WP12 series

- HOWO 6×4 tractor, 4×2 cargo truck, 8×4 dump truck, mixer, mining truck
