5 Ton Hangcha Forklift Brake Shoe Assembly OEM A01C3-70301
- Original arc mold, accurate radian, mounting hole distance and lining size perfectly match brake drum of 5-ton Hangcha forklift, direct replacement without grinding modification
- Thickened high-strength steel shoe body stamped with great toughness, anti-deformation and anti-breakage under heavy-load braking
- High-density asbestos-free friction lining with stable friction coefficient, sensitive braking on dry & wet ground without vibration or deviation
- High-temperature vulcanization bonding firmly connects lining and steel shoe, prevent lining peeling and cracking under frequent heavy braking
- Complete assembly with matched springs, rollers and positioning pins, ready for installation without separate small parts purchase
- Solve soft braking, brake noise, one-side braking, dragging overheat and worn lining, extend service life of brake drum
Parameters:
OEM Part No.: A01C3-70301
Product Type: Forklift Brake Shoe Assembly / Brake Shoe with Lining Assembly
Applicable Equipment: 5 Ton Internal Combustion Hangcha Forklift
Applicable Position: Rear Wheel Drum Brake of Forklift
Core Measured Dimension Specifications
1. Matched Brake Drum Inner Diameter: 320mm
2. Effective Brake Lining Width: 80mm
3. New Lining Thickness: 12mm
4. Single Shoe Arc Length: 475mm
5. Shoe Steel Plate Thickness: 6mm
6. Set Quantity: 2 Pcs per rear wheel set
Material: Thickened stamped steel shoe body, asbestos-free wear-resistant brake lining, 65Mn return springs, carbon steel rollers & pins
Technology: Steel stamping & bending, rust removal phosphating, high-temperature vulcanization lining bonding, precision punching, pre-assembly inspection
Performance: Sensitive braking, wear & high temperature resistant, anti-lining peeling, vibration-free braking, anti-rust, no brake dragging
Applicable Faults: Insufficient braking force, abnormal brake noise, thinned worn lining, one-side brake deviation, dragging & overheated hub, peeled & cracked brake lining
Introduction:
Brake shoe assembly OEM A01C3-70301 is the core braking component of rear drum brake for 5-ton Hangcha forklift. It realizes deceleration and parking by squeezing brake drum with friction lining. After frequent heavy-load braking in factory, the lining of original brake shoe will wear thin and harden with abnormal noise; deformed shoe and weakened spring force cause soft braking, unilateral deviation and overheated dragging hub. In severe cases, lining peeling leads to total braking failure. This complete brake shoe assembly adopts original radian matching 320mm brake drum, thick steel shoe equipped with wear-resistant asbestos-free lining bonded under high temperature to avoid delamination. The full set includes return springs, rollers and positioning pins for easy installation. After replacement, braking force is even and sensitive to eliminate brake noise and dragging, protect brake drum from scratch, an essential spare part for brake system maintenance of 5-ton Hangcha forklift.
