3 Ton Hangcha Forklift Engine Stop Cable OEM Part No.30DE-532000

3 Ton Hangcha Forklift Engine Stop Cable OEM Part No.30DE-532000

Original matched total length and snap connectors on both ends fully fit 3-ton Hangcha forklift, direct installation without cutting or length modification
Multi-strand thick galvanized steel wire inner core with high tensile strength, anti-wire breakage and elongation after frequent pulling
Thickened wear-resistant PVC outer sheath, bending, oil and aging resistant, anti-crack & wire exposure under long bumpy driving
Injection molded fixed connectors on both ends for firm connection without falling off, smooth pulling without jamming and quick reset after shutdown
Low-friction built-in lubricating liner reduces friction between steel wire and sheath for effortless push and pull
Solve cable jamming, shutdown failure, elongated cable unable to cut fuel and rust caused by cracked sheath, stabilize engine shutdown control

Parameters:

OEM Part No.: 30DE-532000

Product Type: Forklift Engine Stop Cable / Shutdown Cable Assembly

Applicable Equipment: 3 Ton Internal Combustion Hangcha Forklift

Applicable Position: Between cab shutdown handle and engine fuel cut-off mechanism

Core Measured Dimension Specifications

1. Total Length of Cable Assembly: 1450MM

2. Inner Steel Wire Diameter: 2.2MM

3. Outer Sheath Outer Diameter: 8MM

4. Operating Stroke: 75MM

5. Connector Snap Specification at Both Ends: Standard Plastic Snap

Material: Multi-strand galvanized steel wire core, low-friction plastic liner, thickened PVC protective sheath, injection molded connector ends

Technology: Twisted & galvanized anti-corrosion steel wire, extruded sheath, integrated high-temperature injection molding for ends, full smoothness inspection

Performance: High tensile resistance anti-elongation, oil & bending resistant, smooth pulling, fast reset, anti-rust & anti-breakage

Applicable Faults: Stiff shutdown handle, no rebound after release, fuel cut failure, elongated cable causing shutdown malfunction, cracked sheath leading to rusted & broken steel strands

Introduction:

Engine stop cable OEM Part No.30DE-532000 is a special shutdown control part for diesel engine of 3-ton Hangcha forklift. The cab shutdown handle pulls the engine fuel cut fork through the cable to cut off fuel supply and shut down the engine. After long-term oil pollution erosion and frame bump tension, the original stop cable is prone to cracked sheath, rusted broken steel wire and elongated cable, resulting in stiff handle and weak reset. In severe cases, engine shutdown failure brings potential safety hazards. This stop cable adopts original standard total length of 1450MM, multi-strand galvanized steel wire matched with wear-resistant PVC sheath, injection molded connectors on both ends fit original mounting points, and built-in lubricating liner ensures smooth push and pull. Fully universal assembly size without cutting or modification. After replacement, shutdown operation is light and sensitive with quick reset after release, stably control engine fuel cut and shutdown, a common wearable spare part for engine maintenance of 3-ton Hangcha forklift.
