3 Ton Hangcha Forklift Steering Knuckle OEM Part No.N163-22003-001
- Integral original casting, kingpin holes, wheel spindle and brake base plate mounting holes fully match 3-ton Hangcha forklift, direct installation without reaming or grinding
- High-strength ductile iron with stress relief annealing, impact resistant and crack-proof under heavy-load turning and bumpy road
- Precision turning for spindle and kingpin holes with high coaxiality, no clearance after bearing assembly, smooth front wheel steering without jamming
- Multi-layer anti-rust coating, anti-corrosion in humid and dusty factory environment for longer service life
- Standard assembly clearance matched with kingpin, bushing and oil seal, light steering after replacement, no wheel deviation or unilateral tire wear
- Solve stiff steering, knuckle cracks, spindle wear and front wheel wobble, cut overhaul cost of steering axle
Parameters:
OEM Part No.: N163-22003-001
Product Type: Forklift Steering Knuckle / Steering Spindle
Applicable Equipment: 3 Ton Internal Combustion Hangcha Forklift
Applicable Position: Front steering axle, load-bearing steering component of front wheel hub
Core Measured Dimension Specifications
1. Kingpin Mounting Hole Diameter: 42MM
2. Wheel Spindle Outer Diameter: 50MM
3. Center Distance of Brake Base Plate Fixing Holes: 135MM
4. Total Length of Steering Knuckle: 248MM
5. Matching Front Wheel Bearing Model: 7508
Material: High-strength Ductile Iron
Technology: Integral precision casting, stress relief annealing, CNC precision turning, hole reaming, anti-rust surface painting
Performance: Heavy load capacity, impact resistance, high toughness, anti-crack, small steering clearance, anti-rust & wear resistant
Applicable Faults: Laborious heavy steering, front wheel wobble & deviation, grooved worn spindle, cracked & broken steering knuckle, abnormal unilateral tire wear
Introduction:
Steering knuckle OEM Part No.N163-22003-001, also known as forklift spindle, is the critical load-bearing steering part of front steering axle for 3-ton Hangcha forklift. It bears full front wheel load and realizes left & right steering together with kingpin. After long-term heavy load and frequent impact during turning, original steering knuckle suffers spindle wear, body cracks and enlarged kingpin hole clearance, resulting in stiff steering, severe front wheel wobble and uneven tire wear. Severe crack breakage will lead to steering failure with huge safety hazard. This knuckle adopts original standard casting dimension, ductile iron with excellent toughness, precisely machined mounting holes and spindle, perfectly matched with original kingpin, wheel hub and brake base plate. After replacement, steering operation becomes light and smooth to eliminate wheel wobble and deviation, effectively protect bearings, kingpin, tires and other parts, an essential original spare part for steering system maintenance of 3-ton Hangcha forklift.
