3 Ton Hangcha Forklift Steering Linkage Repair Kit OEM Part No.N163-220067-000
- Complete set of wearable parts: steering ball joint, wear-resistant bushing, corrugated dust rubber boot, adjusting gaskets and positioning pin shaft. One set finishes tie rod maintenance without scattered purchasing
- Original standard fitting dimensions, compatible with tie rod assembly of 3-ton Hangcha forklift, no loose clearance after assembly and smooth steering without jamming
- High-hardness alloy ball joint with precision ground spherical surface, resist wear and looseness under frequent heavy-load steering for accurate steering without free play
- Thickened corrugated dust boot blocks sediment and dust, lock internal lubricating grease to avoid dry grinding and abnormal noise of ball joint
- Matching adjusting gaskets precisely control steering clearance, eliminate front wheel shake after replacement and prevent unilateral tire wear
- Fully solve loose tie rod, steering free play, turning noise and vehicle deviation, reduce labor cost from repeated disassembly
Parameters:
OEM Part No.: N163-220067-000
Product Type: Complete Forklift Steering Tie Rod Linkage Repair Kit
Applicable Equipment: 3 Ton Internal Combustion Hangcha Forklift
Matching Parts: Steering Knuckle N163-22003-001, King Pin Repair Kit A300-KIT
Applicable Position: Connecting position at both ends of left and right steering tie rod on forklift front axle
Kit Contents & Core Dimension Specifications
1. Ball Joint Pin Shaft Diameter: 30MM
2. Ball Joint Spherical Outer Diameter: 42MM
3. Matching Aperture of Dust Boot: 30-44MM
4. Adjusting Gasket Thickness: Two specifications 0.5MM / 1MM
5. Built-in Wear-resistant Bushing Inner Diameter 30MM, Outer Diameter 38MM
Material: Quenched 40Cr alloy ball joint, wear-resistant copper bushing, weather-resistant rubber dust boot, carbon steel adjusting gaskets
Technology: Integral quenching & tempering for ball joint, mirror finish grinding for spherical surface, integral compression molding for rubber boot, pre-assembly clearance inspection for whole kit
Performance: Wear & impact resistance, dust & water sealing, small steering clearance, no free play, anti-looseness under long heavy load
Applicable Faults: Excessive steering clearance, front wheel shake at high speed, chassis noise during turning, loose tie rod, forklift driving deviation, abnormal unilateral tire wear
Introduction:
Steering linkage repair kit OEM Part No.N163-220067-000 matches front steering axle of 3-ton Hangcha forklift, used together with steering knuckle and king pin repair kit. It is a full set of wearable replacement parts for tie rod ball joint position. After long-term heavy load and frequent steering in factory, the tie rod ball joint bushing will wear continuously, and aging cracked dust boot allows sediment ingress. Loss of lubricating grease leads to loose ball joint, large steering free play, front wheel shake & deviation and metal noise during turning, aggravating abnormal tire wear. This repair kit contains all accessories needed for maintenance. The quenched alloy ball joint features high wear resistance, thick corrugated dust boot provides long-term sealing, and multi-spec adjusting gaskets calibrate steering clearance precisely. All parts share universal dimensions with original tie rod. After replacement, steering operation is tight without free play for stable driving without deviation, effectively protect core parts such as tie rod and steering knuckle, being an essential complete kit for steering system overhaul of 3-ton Hangcha forklift.
