5 Ton Hangcha Forklift Mast Side Roller,

5 Ton Hangcha Forklift Mast Side Roller,

Original matching size inner diameter 58MM, outer diameter 80MM, accurate shaft hole and roller width perfectly fit mast of 5-ton Hangcha forklift, direct replacement without machining
Integrally quenched high-carbon alloy steel roller body with high surface hardness, resist abrasion, grooving and deformation under long heavy-load lifting
Built-in double sets of precision needle bearings for smooth low-resistance rotation, no jamming or noise during carriage lifting
Double-layer dustproof oil seals on both ends block dust, silt and water, prevent bearing rust and seizure caused by oil loss
Thickened & widened roller design with excellent lateral load capacity, reduce mast shake and improve stacking stability
Solve worn rollers, left-right mast shake, lifting blockage and metal friction noise, extend service life of mast guide rails

Parameters:

OEM Part No.: 4M3F-20200-C

Product Type: Forklift Mast Side Roller / Mast Guide Roller

Applicable Equipment: 5 Ton Internal Combustion Hangcha Forklift

Applicable Position: Lateral limit guide position of inner and outer forklift mast

Core Measured Dimension Specifications

1. Roller Outer Diameter: 80MM

2. Roller Inner Bore Diameter: 58MM

3. Total Roller Width: 36MM

4. Matching Pin Shaft Diameter: 58MM

5. Built-in Bearing Type: Needle Roller Bearing

Material: High-carbon alloy steel roller, high-hardness needle rollers, high-temperature weather-resistant rubber oil seal, long-life lubricating grease

Technology: Forging blank, integral high-frequency quenching, outer circle precision grinding, bearing press fitting, grease injection & sealing, finished product rotation inspection

Performance: Heavy load capacity, wear & extrusion resistance, smooth rotation, dust & water proof, anti-seizure, low noise

Applicable Faults: Stiff & blocked mast lifting, concave worn roller, left-right shaky carriage, metal friction noise during lifting, seized non-rotating roller bearing

Introduction:

Mast side roller OEM Part No.4M3F-20200-C is the key lateral guide and load-bearing component for lifting mast of 5-ton Hangcha forklift, size inner diameter 58MM × outer diameter 80MM. Installed on both sides of mast rails, it limits lateral shift of carriage and bears lateral extrusion force. After frequent lifting and lateral heavy load extrusion, original side rollers are prone to worn grooves and rusted bearings due to dust ingress, leading to shaky mast, lifting jamming and harsh friction noise, reducing stacking accuracy and operation safety. This roller adopts original standard size 58MM×80MM, quenched alloy steel roller body, double built-in needle bearings and double-layer dustproof seals to lock grease for long service life. Fully compatible with original pin shafts and guide rails. After replacement, mast lifts smoothly and stably without shake or noise, and prevents scratch damage to mast rails, being a common wearable replacement part for mast system of 5-ton Hangcha forklift.
