Forklift Instrument Cluster Assembly

Original integrated mold housing, mounting hole spacing and wiring plugs fully match A30 series 3-ton Hangcha forklift, direct installation without rewiring
Multi-function integration: water temp gauge, fuel gauge, working hour meter, indicator lamps for turn signal, charging, oil pressure, preheating, air filter and water-oil separator alarm
Stepper motor pointer + LCD Chinese fault prompt, accurate reading with circulating pop-up fault codes for easy maintenance
High-bright backlight panel with clear visibility at night & dim warehouse, even light transmission without dark area
Waterproof multi-pin integrated plug, dust & moisture resistant, avoid short circuit & burnt wiring under dusty & oily workshop environment
Integrated flame-retardant plastic housing, vibration & aging resistant, real-time monitor vehicle operating condition after replacement to prevent engine failure in advance

Parameters:

OEM Part No.: A300-740000-001

Product Type: Forklift Multi-Function Combined Instrument Cluster Assembly

Applicable Equipment: 3 Ton Hangcha A30/A35 National III Internal Combustion Forklift (CPC30/CPC35)

Applicable Position: Instrument mounting position above steering wheel in forklift cab

Core Measured Dimension Specifications

1. Total Housing Length: 298MM

2. Total Housing Width: 195MM

3. Center Distance of Mounting Holes: 160MM

4. Wiring Plug Specification: Dual Waterproof Connectors (9Pin+13Pin)

5. Rated Operating Voltage: DC 12V

Integrated Display Functions

Water temperature display, fuel level, total working hours, left/right turn signal, charging indicator, oil pressure alarm, preheating prompt, air filter clogging alarm, water accumulation alarm of water-oil separator

Material: Flame-retardant ABS housing, high-transmittance tempered glass panel, stepper motor movement, waterproof copper core connectors, LED backlight beads

Technology: Integral injection molding, circuit board SMT chip mounting, stepper motor calibration, backlight brightness verification, whole machine power-on aging & leakage inspection

Performance: DC 12V compatible, dust & water proof, vibration resistant, small reading error, sensitive fault prompt, no black screen during long-term operation

Applicable Faults: No backlight & blank screen, stationary water temp/fuel pointer, frozen hour meter, failed oil pressure/charging alarm lamp, dead turn signal lamp, internal short circuit & burnt plug

Introduction:

Instrument cluster OEM Part No.A300-740000-001 is the core monitoring component for whole vehicle working condition of 3-ton Hangcha A30 series internal combustion forklift. It collects multi-channel sensor signals to real-time display water temperature, fuel level and working hours. Dual reminder of indicator light & Chinese text will be triggered when hidden dangers such as low oil pressure, charging failure, clogged air filter and accumulated water in water-oil separator occur, reminding operators to maintain timely. After long-term workshop vibration and erosion of oil & moisture, original instrument easily suffers broken backlight, stuck pointer, invalid timing and dead alarm lamp, unable to predict engine faults and bring risks of overheating or cylinder scuffing due to oil shortage. This gauge adopts original standard 12V voltage with dual waterproof plugs for direct plug-and-play. Stepper motor ensures accurate & stable pointer reading, high-bright backlight adapts day & night operation, flame-retardant housing resists vibration & cracking. Fully compatible with original mounting size. After replacement, all working data are clearly visible with early fault warning, effectively protect engine and hydraulic system, an essential wearable electric control part for cab of 3-ton Hangcha A30 forklift.
