Forklift Clutch Disc OEM XL40C-Z(P1)

Measured original standard dimensions: outer disc diameter 275mm, spline inner bore 62mm, 18 spline teeth, friction lining thickness 4.2mm, fully match XL40C forklift, direct replacement without machining
High-density wear-resistant friction lining with stable friction coefficient, no slipping under heavy load and sufficient torque transmission
High-temperature flame retardant formula, anti-carbonization and anti-ablation during frequent start-stop and long climbing operation
Evenly arranged shock-absorbing springs buffer clutch impact, smooth shifting without vibration and harsh noise
Thickened high-strength steel substrate with excellent toughness, anti-twist and anti-crack, protect pressure plate and release bearing synchronously
Complete measured dimension labels for convenient purchasing, inspection and installation, fully solve slipping, stiff shift and burning odor problems

Product Parameters:

OEM Part No.: XL40C-Z(P1)

Product Type: Forklift Clutch Driven Disc / Friction Disc

Applicable Equipment: Manual gearbox of 4 Ton Internal Combustion Forklift Model XL40C-Z(P1)

Applicable Position: Clutch transmission assembly between engine and gearbox

1. Friction Disc Outer Diameter: 275mm

2. Spline Inner Bore Diameter: 62mm

3. Single Friction Lining Height (Friction Layer Thickness): 4.2mm

4. Overall Assembly Thickness of Clutch Disc: 26mm

5. Inner Spline Teeth Quantity: 18 Teeth

Material: Asbestos-free wear-resistant friction lining, high-rigidity stamped steel core, damping shock-absorbing springs

Technology: High-temperature hot pressing composite, precision spline milling, pre-assembled damping springs, flatness calibration

Performance: High friction coefficient, withstand 380℃ high temperature, anti-slip, shock absorption & noise reduction, wear-resistant & anti-thinning

Applicable Faults: Clutch slipping, weak startup, stiff gear shift, burnt & thinned clutch disc, burning odor during operation, incomplete clutch separation

Clutch disc OEM XL40C-Z(P1) is the core power transmission component for manual gearbox of 4-ton XL40C forklift, which transmits engine power through friction linings on both sides. This product is marked with full set of measured original dimensions: outer diameter 275mm, 18 inner spline teeth, friction lining thickness 4.2mm, transparent size parameters with zero error for purchasing verification. After long-term heavy load and frequent clutch operation, the friction layer of original clutch disc will suffer continuous wear and high-temperature ablation, and the shock-absorbing springs will fail due to fatigue, causing power slipping, weak startup, unsmooth gear shifting and burning odor in the engine compartment. This clutch disc adopts original matching size, hot-pressed with premium high-temperature and wear-resistant friction materials, and equipped with balanced shock-absorbing springs to buffer impact during clutch engagement for stable power output. After replacement, it can effectively protect precision parts such as gearbox gears, pressure plates and release bearings, being an essential replacement spare part for clutch system maintenance of 4-ton forklift model XL40C-Z(P1).
