Forklift Clutch Pressure Plate OEM DSK330 / XL137Y-Z(P1)
- Original standard 330mm outer diameter, mounting pitch and finger height fully match XL40C forklift, can be replaced together with XL40C-Z(P1) clutch disc
- Thickened ductile iron pressure surface with fast heat dissipation and high temperature resistance, no warping under long heavy load, stable long-lasting clamping force
- Integrally quenched release fingers, wear and impact resistant, hard to wear or crack after frequent clutching, smooth gear shifting without jamming
- High-precision three-finger spring assembly with even pressure, smooth clutch engagement without vibration and power slipping
- Integral cast housing with accurate flange holes, direct replacement for original parts without drilling or grinding
- Perfectly matched OEM-series clutch disc three-piece kit, fully solve insufficient power, burnt disc, incomplete separation and abnormal noise, reduce overhaul cost
Parameters:
OEM Part No.: DSK330 / XL137Y-Z(P1)
Product Type: Forklift Clutch Pressure Plate Assembly / Clutch Cover
Applicable Equipment: Manual Gearbox of 4 Ton XL40C Series Internal Combustion Forklift
Matching Parts: Clutch Disc Model XL40C-Z(P1)
Applicable Position: Clamping assembly between engine flywheel and clutch disc
Core Measured Dimension Specifications
1. Overall Outer Diameter of Pressure Plate: 330mm
2. Effective Friction Inner Diameter: 190mm
3. Total Assembly Thickness: 48mm
4. Quantity of Release Fingers: 3 Fingers
5. Matching Clutch Disc Spline Teeth: 18 Teeth
6. Mounting Bolt Pitch Circle Diameter (PCD): 368mm
Material: Ductile iron pressure surface, quenched 45# steel release fingers, high-strength springs, cast steel housing
Technology: Integral casting, stress relief annealing, precision surface grinding, high-frequency quenching for fingers, spring pressure calibration
Performance: Sufficient clamping force, withstand 400℃ high temperature, anti-warp surface, wear-resistant fingers, thorough separation, stable transmission
Applicable Faults: Clutch slipping, insufficient startup power, stiff gear shift due to incomplete separation, worn & broken fingers, high-temperature surface deformation, clutch vibration and abnormal noise
